Upenders for coil, dies and other heavy materials


Upender or Tilter is widely used all over the world providing modern demanding industries with enhanced productivity and extreme safety during  90°, 180° and 360° tilting of large and very heavy materials. Overhead cranes or forklifts to upend heavy loads are widely used nowadays by the companies requiring a high level of safety and productivity. With the current metalworking industry changing so rapidly, flat deck mold upender provides modern problem-solving solutions for industrial handling of mold, tooling and die

Dedicated machine for upending allows an operator to unload overhead cranes. Upender is completely safe since it avoids holding the load raised during tilting, in this way operators are safe from difficult and dangerous manoeuvres. Morello supplies flat deck upender for mold, dies, coils, castings and other material handling in a variety of manufacturing industries all over the world.


Morello’s upenders can be customized according to special needs: payload, loading deck size and covers, tilting speed and other options can be studied together with the client. Morello pays particular attention to design of heavy load solutions with high capacity from 10 tonnes to over 200 tonnes.

Technical characteristics

from 1 ton to over 200 tons
on request
Tilting angle
90° / 180° / 360°
Loading deck material
steel, wood, plywood, rollers
Tilting system
hydraulic cylinders, electric gear motors, chains
pendant panel, remote controller, pulpit, customer WMS/ERP
Load locking and centering
on request
Operating environment
indoor, outdoor, offshore
Safety devices
laser scanners, sensitive bumpers, photoelectric sensors
See the technology
Industry 4.0 ready
on request
See the technology
Hazardous areas conform (EX)
on request (ATEX, IECEx, NEC 500)
See the technology
on request
